Technical parameters
Project | Status | Results | ||
Optical (instrument) | Transmittance | Energised (ON) | Approximately 78 per cent (+/-3 per cent) | |
Energised (OFF) | <1 per cent | |||
Haze | Energised (ON) | <7% | ||
Energise (OFF) | >90% | |||
Viewing Angle | Energised (ON) | Approx. 150° | ||
Electrical | Power Adapter | Energise (ON) | 65VAC | |
Response Time(room temperature condition) | Energise (OFF-ON) | Approx. 10 ms | ||
Energise - Disconnect (ON-OFF) | 200 ms | |||
Power Consumption | Energise (ON) | 5W/m/h | ||
Environmental | Operating Temperature | Energise-Disconnect (ON-OFF) | -10°C to 60°C | |
Storage Temperature | Energise-Disconnect (ON-OFF) | -20°C to 70°C | ||
Lifetime | Service Life | Power On-Off (ON-OFF) | Over 10 years | |
Sound | STC value | 6+6 Tempered Glass | 39dB |
