Technical parameters
| Door frame profiles | Wrapped frame type, flat frame type, pairs of clips type (can be customised according to customer needs) | |||
| Frame Advantages | According to the actual site of any size opening | |||
| Materials | Thickness of the steel plate of the door frame:1.5mm, Thickness of the steel plate of the door leaf:1.0mm. | |||
| Surface treatment | Spraying, and baking paint (colour can be customized according to customer's requirement) | |||
| Wind Pressure Resistance P3(KPa) |
2.8 | Acoustic performance | Rw=33dB Grade III (GB/T8485-2008) | |
| 100.8KPa | Anti-collision performance | Comply with GB/T20909-2007 | ||
| Q2=1.0/2.1 | Thermal insulation performance | Heat transfer coefficient K=2.8W/(m2.K)Grade V | ||
| Filling | Flame retardant paper honeycomb | Fireproof aluminium honeycomb | Rock wool | Polyurethane foam |
| Hardware | Yatai custom stainless steel hinge, aluminium alloy hinge | |||
| YT one-piece executive lock | YT split actuator lock | Pressure lock | Available according to the customer's option | |
| Surface treatment of door frame | Sand electric white | Spraying | Electrophoresis | Available according to the customer's option |
Optional motors and induction devices can be used to achieve automatic opening and closing.
The door frame adopts a single-slot and double-slot integrated unique door frame airtight structure to meet the different needs of various environments.
The steel door is made of environmentally friendly galvanized sheet, with electrostatic spraying on the surface, anti-fouling, and green environmental protection.
It has the advantages of heat preservation, sound insulation, moisture resistance, and easy cleaning.
The edge of the door leaf is tightly stitched with a single seam to reduce the breeding of bacteria, and windows of different shapes can be customized according to the needs of the hospital.
Hardware characteristics:
Yatai's custom reinforced stainless steel bearing hinges combine strength, silent operation, aesthetic appeal, and durability.
Available in stainless steel or aluminum alloy, our handles are ergonomically designed for ease of use and come in multiple styles to suit diverse needs.
Yatai's custom-engineered hardware features a stainless steel lock mechanism, delivering secure and reliable performance with smooth, noiseless operation.
Remarks: We can accept customers' demand to make non-standard products with different specifications and models, and the doors and windows can be selected with different shapes and grades of glass, such as toughened glass, fireproof glass, and bulletproof glass.
