DOOR WIDTH | Door opening width +80 | DOOR HIGHT | Door opening width +20 |
DOOR THICKNESS | 42mm | DOOR WEIGHT | 60KG |
SUPPLY VOLTAGE | AC220±10%, 50~60Hz | OPENING HOURS | 2-20S (adjustable) |
OPENING SPEED | 250-500mm/s (adjustable) | CLSEING SPEED | 250-500mm/s (adjustable) |
MANUAL THRUST | <100N | TIGHT CLOSING FORCE | >70N |
POWER CONSUMPION | <150W | WORKING TEMPERATURE | -20°C-+50°C |
The external wall design of the power beam makes installation and maintenance healthier.
The built-in anti-collision belt has a smooth and flat surface.
The door body is designed to automatically sink, with a maximum sinking distance of 15mm, and has stronger air tightness.
The door body is sealed and pressurized, and the sealed state is 10mm inward, which can more effectively isolate the internal and external environment circulation.
The unique track structure allows the door body to be fully opened to reach the top of the power beam.
The inner lining is lead plate, and the lead glass leakage-proof design of the observation window can effectively isolate radiation leakage.
